CHAIN DRIVEN BELT 31 conveyor belt with chain attached to both sides of normal wire conveyor belt. Belt and chain are matched by stay pin. These belts are made by fitting chains to both sides of ordinary wire conveyor belt. The belt and chain are synchronized through stays (cross supports). Feature Advantages ●Since the chain is driven by sprockets, there is no meandering. Because chain is driven by sprocket, meandering does not occur. ●By adjusting the pitch of the belt, it can be assembled into various types of chains. Various types of chain can be applied by adjusting belt pitch. ●The chain and stay make it easy to install francs and stoppers. It is easy to attach side guard and product stopper in combination with chain and stay. Chain c/c Chain c/c Chain c/c Chain core K2 Stepin type K2 stay pin type K2 GK-1 type K2 GK-1 type K2 GK-1 type Type of stay 1stpin type Stay pin type ●It is a general type that incorporates a step-cut round bar (stee pin) into the pins of the chains on both sides, and the belt is a type in which the thickness of the lassen is adjusted so that the round bar passes through the lassen. The step-cut round rod (stay pin) is fitted to chain at both sides, and the thickness of spiral is adjusted so that the round rod passes inside the spiral. Constant thickness Constant thickness Large lassen Embedded With large spiral lassen Embedded With triangular spiral CHAIN DRIVEN BELT 75 76 77 Stepin type Stay pin type 74 Figure 18 Figure 19 Figure 19 Figure 19:
