WIRE MESH MIST ELIMINATOR

Characteristics

・Due to its lightweight, it is economical and available at a low cost.
・No need to pay for the maintainance cost.
・Pressure loss is very low because the surface area is very large.
・ It is also easy to use for small device.
・It is less constrained by dimensions and shapes during design.
・It is easy to install on existing equipment.
・Excellent in heat resistance and corrosion resistance.
・High collection efficiency close to 100%.
・Highly uniform and very low pressure loss due to uneven distribution.

Products

•

  ＳＫ－８０
  It is the one that can be used at the highest airflow velocity among all styles
  ・Especially when the low pressure loss is required.
  ・Conditions where clogging is likely to occur
  ・Collection of large mist.
  ・When high efficiency is not required.

•

  ＳＫ－１９２
  This is the most commonly used style.
  It is possible to obtain almost 100% collection efficiency for particles of 5 to 10μm. The pressure loss is slightly higher than the previous type.

•

  ＳＷ－２１６
  Used to collect micro mist. Especially when the mist concentration is particularly low, at 10g/m3 or below, use of 200 to 300mm thickness will be effective.

•

  ＳＷ－４３２
  It is the most high-density style. It is used to collect very fine mist at high efficiency, which is higher than SW-216. High efficiency is possible even if the thickness is thin.
